8’ LED Commercial Vaportight with Wattage and CCT Selector IMVP8FT
Description:
The IMVP8FT-65-75-90W-3CCT series Vapor Tight Fixtures are designed to save energy and meet low light egress requirements. It’s optimal for underground parking garage compliance. Also, it’s perfect for use as utility lighting, parking garage, and stairwell lighting where applicable building and safety codes need to be met. These fixtures are DLC and UL Certified. They are popular in parking lots, warehouses, public areas, and other commercial areas.
TECHNICAL SUMMARY
|
LUMENS |
WATTS |
EFFICACY |
CRI |
VOLTAGE |
BEAM º |
CCT |
PF |
LIFE |
OPERATING TEMP. |
|
8450 9750 11700 |
65W 75W 90W |
130 lm/W |
80 |
120V, 277V |
140 |
3500K 4000K 5000K |
>0.9 |
100,000 hrs |
-40ºF ~ 104ºF |
CONSTRUCTION
- Unit includes heavy duty plastic frame, LED array, heat sink, and lens.
- High quality PC lens.
- Efficiency LED array
- Diffuse for uniform illumination.
- CRI 80+
DRIVER
- 120-277V universal input voltage.
- 0-10V smooth flicker free dimmable.
MOUNTING
- Pendant Mount with V-Hook
- Surface mounting
LISTING
- DLC Listed
- UL 1598 suitable for wet locations
- UL 8750 LED equipment in Lighting Products
WARRANTY
- 5 years manufacturer warranty.
- Terms and conditions may apply.
