4"/6" Metal Trim Surface Mount Light with Motion Sensor - White IMRSMMS

Description:

The IMRSMMS Series has an elegant design and will provide exceptional performance in general lighting applications for home, hotel, motel, and commercial properties, and can also serve as a cost-effective temporary lighting solution. Precision-engineered optical stack creates uniform light distribution that maximizes lumen output. it has smooth dimming features and is compatible with a wide variety of dimmers.

Perfect use for residential housings, condominiums, business buildings, hotels, and the hospitality industry.

Contact Us

TECHNICAL SUMMARY

MODEL #

LUMENS

WATTS

EFFICACY

CRI

VOLTAGE

BEAMº

CCT

PF

LIFE

OPERATING TEMP.

IMRSMMS410-30K-WH

650

10W

65 lm/W





90



120V-

60 Hz





110º





3000K





>0.9





50,000 hrs





-5ºF ~ 104ºF

IMRSMMS614-30K-WH

1000

14W

71 lm/W

CONSTRUCTION

  • Unit includes die-cast metal housing, LED array, heat sink, lens, and metal trim.

OPTICS

  • High quality PC lens
  • Efficiency LED array
  • Diffuse for uniform illumination

DRIVER

  • High efficiency integral 120V 60Hz constant current dimmable.
  • Smooth flicker free deep dimming to 10%

MOUNTING

  • Surface mount on junction box
  • Surface mounting bracket included>

LISTING

  • ETL Listed, Energy Star Listed, Suitable for Wet Locations, Title 24 JA8-2022, RoHS

WARRANTY

  • 5 years manufacturer warranty, consult factory for more details. Terms and conditions may apply.

LUTRON

  • TGCL-153PH-WH
  • DVCL-153PR
  • P-PKG1W-WH-R
  • CTCL-153PDH-WH

LEVITON

  • R00-RNL06-TW
  • 50-IPL06-10M

4"/6" Metal Trim Surface Mount Light with Motion Sensor - White IMRSMMS

IMRSMMS410-30K-WH

IMRSMMS614-30K-WH
